Main Technical Parameters
| Model | JH-FM700D-A | JH-FM900D-A | JH-FM1100D-A | JH-FM1300D-A | JH-FM1500D-A | JH-FM1700D-A | JH-FM1900D-A |
| Applicable Raw Materials | HDPE/ LDPE/ LLDPE | HDPE/ LDPE/ LLDPE | HDPE/ LDPE/ LLDPE | HDPE/ LDPE/ LLDPE | HDPE/ LDPE/ LLDPE | HDPE/ LDPE/ LLDPE | HDPE/ LDPE/ LLDPE |
| Product Width | 200-600mm | 300-800mm | 400-1000mm | 800-1200mm | 1000-1400mm | 1100-1600mm | 1200-1800mm |
| Product Thickness | 0.015-0.2mm | 0.015-0.2mm | 0.015-0.2mm | 0.015-0.3mm | 0.015-0.4mm | 0.015-0.5mm | 0.015-0.6mm |
| Maximum Extrusion Capacity | 50-80kg/hr | 60-90kg/hr | 70-110kg/hr | 90-130kg/hr | 110-150kg/hr | 120-160kg/hr | 130-190kg/hr |
| Extrusion Machine | |||||||
| Screw Diameter | Φ45x2mm | Φ50x2mm | Φ55x2mm | Φ60x2mm | Φ65x2mm | Φ70x2mm | Φ75x2mm |
| Draw Ratio Of Screw | 30:1/ 32:1 | 30:1 /32:1 | 30:1 /32:1 | 30:1 /32:1 | 30:1 /32:1 | 30:1 /32:1 | 30:1 /32:1 |
| Screw Material | SACM-645/38 CRMOALA | SACM-645/38 CRMOALA | SACM-645/38 CRMOALA | SACM-645/38 CRMOALA | SACM-645/38 CRMOALA | SACM-645/38 CRMOALA | SACM-645/38 CRMOALA |
| Material Of Material Cylinder | SACM-645/38 CRMOALA | SACM-645/38 CRMOALA | SACM-645/38 CRMOALA | SACM-645/38 CRMOALA | SACM-645/38 CRMOALA | SACM-645/38 CRMOALA | SACM-645/38 CRMOALA |
| Material Cylinder Cooling | 180w×2-2 | 180w×2-2 | 250w×3-2 | 250w×3-2 | 370w×3-2 | 370w×4-2 | 370w×5-2 |
| Host Power | 15KW×2 | 18.5KW×2 | 18.5KW×2 | 22KW×2 | 30KW×2 | 37KW×2 | 45KW×2 |
| Material Barrel Temperature Control | 3区*2 | 3区*2 | 3 Zones*2 | 4 Zones*2 | 4 Zones*2 | 4 Zones*2 | 5 Zones*2 |
| Average Power Consumption | 18kw | 25kw | 35kw | 42kw | 50kw | 62kw | 75kw |
| Die Head | |||||||
| Die | 60mm(HDPE) 120mm(LDPE) |
80mm(HDPE) 140mm(LDPE) |
100mm(HDPE) 160mm(LDPE) |
120mm(HDPE) 250mm(LDPE) |
140mm(HDPE) 250mm(LDPE) |
160mm(HDPE) 300mm(LDPE) |
180mm(HDPE) 350mm(LDPE) |
| Rotate | 360° | 360° | 360° | 360° | 360° | 360° | 360° |
| Temperature Control | 2区 | 2区 | 3 Zones | 3 Zones | 3 Zones | 4 Zones | 5 Zones |
| Dual Air Outlet Wind Ring | Φ700mm | Φ800mm | Φ800mm | Φ1000mm | Φ1000mm | Φ1200mm | Φ1500mm |
| Fan | 3kw | 4kw | 5.5kw | 7.5kw | 7.5kw | 11kw | 11kw |
| Extraction Device | |||||||
| Pulling Roller Width | 700mm | 900mm | 1100mm | 1300mm | 1500mm | 1700mm | 1900mm |
| Effective Extraction Of Membrane Width | 600mm | 800mm | 1000mm | 1200mm | 1400mm | 1600mm | 1800mm |
| Up And Down Lifting Type | 700mm | 700mm | 700mm | 700mm | 700mm | 700mm | 700mm |
| Traction Speed | 10-100m/min | 10-100m/min | 10-100m/min | 10-100m/min | 10-100m/min | 10-100m/min | 10-100m/min |
| Extract Motor Power | 1.5kw | 2.2kw | 2.2kw | 3kw | 4kw | 5.5kw | 7.5kw |
| Take-Up Device | |||||||
| Roll Up Power | 10N.m | 16N.m | 16N.m | 25N.m | 40N.m | 60N.m | 100N.m |
| Take-Up Speed | 10-100m/min | 10-100m/min | 10-100m/min | 10-100m/min | 10-100m/min | 10-100m/min | 10-100m/min |
| External Dimensions | 4.0×2.3×4.5m | 5.5×2.5×5.5m | 6.0×2.8×6.2m | 7.0×3.0×6.8m | 7.5×3.2×7.2m | 8.0×3.5×7.8m | 8.5×4.0×8.5m |
The AB HDPE LDPE high-speed automatic blown film machine is a blown film machine specifically designed by Jianhao for customers seeking high efficiency and precision. This automatic blown film machine is designed for processing HDPE, LDPE, and LLDPE raw materials, offering excellent material adaptability.
The AB HDPE LDPE high-speed automatic blown film machine utilizes a nitrided twin-screw extrusion system with a length-to-diameter ratio of 30:1/32:1. The screw is made of high-quality SACM-645/38 CRMOALA steel, which offers superior durability and wear resistance, enhancing machine lifespan and product quality. This model can produce films with widths from 200 mm to 1800 mm and thicknesses from 0.015 mm to 0.6 mm, with a maximum extrusion capacity of up to 190 kg/hour. Customers can flexibly adjust the output to meet different production needs.
This AB HDPE LDPE high-speed automatic blown film machine is equipped with a 360° rotating die head, dual air outlet rings, and a multi-zone precise temperature control system. These features ensure uniform film thickness, stable bubble formation, and minimal material waste. The winding system supports traction speeds of 10-100 meters per minute and features automatic tension control, achieving neat and uniform winding, reducing labor costs, and improving product winding quality.
This blown film machine is suitable for food packaging, industrial packaging, agricultural film, and consumer product packaging. Its low total power consumption (average power consumption as low as 18 kW for entry-level models) saves customers on electricity costs. Low maintenance costs ensure stable operation and allow for quick troubleshooting. Thanks to Jianhao's reliable engineering design and rigorous quality control, the AB HDPE LDPE high-speed automatic blown film machine aims to provide long-term stable performance, making it an ideal choice for plastic film manufacturers upgrading their production lines.
Product Features
Advanced AB Twin-Screw Co-Extrusion Technology
This twin-screw AB blown film extrusion machine utilizes advanced AB co-extrusion technology, allowing the use of recycled materials in the middle layer while maintaining high-quality plastic particles in the outer layer. This reduces raw material costs without compromising film strength or transparency.
High Output and Stable Production
Equipped with two high-performance extruders and a nitriding screw, this blown film machine boasts high production efficiency and excellent film quality.
Uniform Film Thickness
Precision dies, dual-airflow rings, and an intelligent temperature control system ensure uniform film thickness, improving overall machine performance and guaranteeing finished product quality.
Intelligent Control
The PLC control system features a touchscreen interface, allowing operators to adjust parameters and monitor the production process based on visualized data, thereby improving overall plant efficiency.
Wide Material Compatibility
Wide Material Compatibility: The twin-screw AB blown film extrusion machine is suitable for processing HDPE, LDPE, LLDPE, and recycled polyethylene materials, providing customers with more flexible production solutions and better raw material compatibility.
Applications
The Twin Screw AB Blowing Film Machine is widely used for manufacturing various plastic films for flexible packaging and industrial applications, including:
- · Shopping Bag Film
- · T-Shirt Bag Film
- · Garbage Bag Film
- · Food Packaging Film
- · Courier Mailing Bag Film
- · Agricultural Mulch Film
- · Industrial Packaging Film
- · Protective Packaging Film
- · Stretch Film Base Film
- · General Polyethylene Packaging Film
This machine is especially suitable for manufacturers seeking to produce high-quality packaging films while reducing raw material costs through AB co-extrusion technology. It is widely applied in the food packaging, retail packaging, logistics, agriculture, and industrial packaging industries.
Our Service
Pre-Sales Consultation
Our experienced sales engineers provide professional machine recommendations based on your production requirements, raw materials, and finished product specifications.
Customized Solutions
We offer customized machine configurations to meet different production capacities, film structures, and packaging applications.
Installation & Training
Professional engineers are available for overseas installation, machine commissioning, and operator training to ensure smooth production.
Quality Assurance
Every machine undergoes strict quality inspection and trial operation before shipment to guarantee reliable performance and stable operation.
Technical Support
Our technical team provides 24/7 online support, remote troubleshooting, and timely maintenance guidance to minimize downtime.
One-Year Warranty
All machines come with a one-year warranty. During the warranty period, we provide free replacement parts for non-human damage and lifetime technical support.
FAQ
1. What is a Twin Screw AB Blowing Film Machine?
A Twin Screw AB Blowing Film Machine is a three-layer co-extrusion film blowing system designed to produce high-quality PE films with an A/B/A structure. The two outer layers (A layer) provide excellent strength, sealing performance, and appearance, while the middle layer (B layer) can use recycled materials or cost-effective resins to reduce production costs.
2. What materials can be processed by the Twin Screw AB Blowing Film Machine?
The machine is suitable for processing various polyethylene materials, including HDPE, LDPE, LLDPE, and recycled PE materials. It is widely used for producing shopping bags, garbage bags, packaging films, agricultural films, and industrial packaging films.
3. What are the advantages of AB three-layer co-extrusion technology?
AB technology improves film performance while reducing production costs. By adding recycled materials into the middle layer, manufacturers can save raw material expenses while maintaining good tensile strength, flexibility, and sealing properties through high-quality outer layers.
4. Why choose a twin screw design for the AB film blowing machine?
The twin screw extrusion system provides better plasticizing performance, more uniform material mixing, and stable extrusion output. It is especially suitable for processing recycled materials and complex film formulations that require excellent dispersion and consistency.
5. What types of films can this machine produce?
The Twin Screw AB Blowing Film Machine can produce various PE films, including:
- Shopping bag film
- Garbage bag film
- Vest bag film
- Packaging film
- Agricultural film
- Recycled plastic film
The final film specifications can be customized according to customers' production requirements.
6. Can recycled materials be used in this machine?
Yes. One of the biggest advantages of the AB structure is that recycled materials can be used in the middle layer. This helps customers reduce raw material costs while maintaining the appearance and mechanical properties of the finished film.
7. How does Jianhao Machinery ensure film quality?
Jianhao Machinery adopts advanced extrusion technology, precise temperature control, stable cooling systems, and optimized screw designs to ensure uniform film thickness, stable bubble formation, and consistent production quality.
8. Is the Twin Screw AB Blowing Film Machine energy-efficient?
Yes. The machine is designed with an optimized extrusion system and efficient components to reduce energy consumption during continuous operation. The AB structure also helps reduce the usage of expensive virgin materials, improving overall production efficiency.
9. What industries can use films produced by this machine?
Films produced by the Twin Screw AB Blowing Film Machine are widely used in:
- Food packaging industry
- Shopping bag production
- Waste management packaging
- Agricultural applications
- Industrial packaging solutions
10. Does Jianhao Machinery provide installation and after-sales service?
Yes. Jianhao Machinery provides professional technical support, machine installation guidance, operation training, and long-term after-sales service to ensure customers can operate the equipment smoothly and efficiently.
